——【型号及规格】———————————————————————————————————————
【直流稳压电源技术参数】:
输入电压:AC220V(或380V) ± 10% / 50Hz
输出电压:0%--100%可调输出 或 固定输出
输出电流:0%--100%可调输出 或 固定输出
电源效应:< 0.3% + 10mV
负载效应: < 0.1% + 10mV
周期与随机漂移:< 0.1% (rms)
短路保护: 输出可短路,短路时有声音报警,短路解除后可自动恢复工作
绝缘电阻:≥5MΩ
相对湿度:<90% (非凝结状态)
满负荷连续工作8小时(40℃环境下长期使用)
环境温度:0-40℃
显示方式:3位半数显电压/电流表
【直流电源主要用途】:
1. 蓄电池充电,PCB暴光灯电源
2. 实验室、电子设备、自动测试设备
3. 电阻器、继电器、电机等电子元件老化,例行试验
4. 电子检验设备、生产流水线设备、通讯设备检测
5. 其它一切需要使用直流电源的场合
【产品规格】
提示
1、以下产品型号及参数,供参考,请以实物为准,如有改动,另行通知。
2、我公司可以定做各种非标直流电源。
3、可加装0-5V,0-10V,4-20mA计算机模拟信号控制,或加装定时、计时功能。
0-5V可调直流稳压电源规格表格 | |||
规 格 |
输出电流 |
输出电压 |
型号 |
0-5V 可调 |
0-2A |
0-5V |
NHWY5-2 |
0-3A |
0-5V |
NHWY5-3 | |
0-5A |
0-5V |
NHWY5-5 | |
0-10A |
0-5V |
NHWY5-10 | |
0-15A |
0-5V |
NHWY5-15 | |
0-20A |
0-5V |
NHWY5-20 | |
0-30A |
0-5V |
NHWY5-30 | |
0-50A |
0-5V |
NHWY5-50 | |
0-80A |
0-5V |
NHWY5-80 | |
0-100A |
0-5V |
NHWY5-100 | |
0-200A |
0-5V |
NHWY5-200 | |
0-300A |
0-5V |
NHWY5-300 | |
0-500A |
0-5V |
NHWY5-500 |
0-15V可调直流稳压电源规格表格 | |||
规 格 |
输出电流 |
输出电压 |
型号 |
0-15V 可调 |
0-2A |
0-15V |
NHWY15-2 |
0-3A |
0-15V |
NHWY15-3 | |
0-5A |
0-15V |
NHWY15-5 | |
0-10A |
0-15V |
NHWY15-10 | |
0-15A |
0-15V |
NHWY15-15 | |
0-20A |
0-15V |
NHWY15-20 | |
0-30A |
0-15V |
NHWY15-30 | |
0-50A |
0-15V |
NHWY15-50 | |
0-80A |
0-15V |
NHWY15-80 | |
0-100A |
0-15V |
NHWY15-100 | |
0-200A |
0-15V |
NHWY15-200 | |
0-300A |
0-15V |
NHWY15-300 | |
0-500A |
0-15V |
NHWY15-500 |
0-30V 可调 |
0-2A |
0-30V |
NHWY30-2 |
0-3A |
0-30V |
NHWY30-3 | |
0-5A |
0-30V |
NHWY30-5 | |
0-10A |
0-30V |
NHWY30-10 | |
0-15A |
0-30V |
NHWY30-15 | |
0-20A |
0-30V |
NHWY30-20 | |
0-30A |
0-30V |
NHWY30-30 | |
0-50A |
0-30V |
NHWY30-50 | |
0-80A |
0-30V |
NHWY30-80 | |
0-100A |
0-30V |
NHWY30-100 | |
0-150A |
0-30V |
NHWY30-150 | |
0-200A |
0-30V |
NHWY30-200 | |
0-300A |
0-30V |
NHWY30-300 | |
0-500A |
0-30V |
NHWY30-500 |
0-60V 可调 |
0-2A |
0-60V |
NHWY60-2 |
0-3A |
0-60V |
NHWY60-3 | |
0-5A |
0-60V |
NHWY60-5 | |
0-10A |
0-60V |
NHWY60-10 | |
0-15A |
0-60V |
NHWY60-15 | |
0-20A |
0-60V |
NHWY60-20 | |
0-30A |
0-60V |
NHWY60-30 | |
0-50A |
0-60V |
NHWY60-50 | |
0-80A |
0-60V |
NHWY60-60 | |
0-100A |
0-60V |
NHWY60-100 | |
0-150A |
0-60V |
NHWY60-150 | |
0-200A |
0-60V |
NHWY60-200 | |
0-250A |
0-60V |
NHWY60-250 | |
0-300A |
0-60V |
NHWY60-300 | |
0-500A |
0-60V |
NHWY60-500 |
0-120V 可调 |
0-2A |
0-120V |
NHWY120-2 |
0-3A |
0-120V |
NHWY120-3 | |
0-5A |
0-120V |
NHWY120-5 | |
0-10A |
0-120V |
NHWY120-10 | |
0-15A |
0-120V |
NHWY120-15 | |
0-20A |
0-120V |
NHWY120-20 | |
0-30A |
0-120V |
NHWY120-30 | |
0-50A |
0-120V |
NHWY120-50 | |
0-80A |
0-120V |
NHWY120-80 | |
0-100A |
0-120V |
NHWY120-100 | |
0-150A |
0-120V |
NHWY120-150 | |
0-200A |
0-120V |
NHWY120-200 | |
0-300A |
0-120V |
NHWY120-300 | |
0-500A |
0-120V |
NHWY120-500 |
0-150V 可调 |
0-2A |
0-150V |
NHWY150-2 |
0-3A |
0-150V |
NHWY150-3 | |
0-5A |
0-150V |
NHWY150-5 | |
0-10A |
0-150V |
NHWY150-10 | |
0-15A |
0-150V |
NHWY150-15 | |
0-20A |
0-150V |
NHWY150-20 | |
0-30A |
0-150V |
NHWY150-30 | |
0-50A |
0-150V |
NHWY150-50 | |
0-80A |
0-150V |
NHWY150-80 | |
0-100A |
0-150V |
NHWY150-100 | |
0-150A |
0-150V |
NHWY150-150 | |
0-200A |
0-150V |
NHWY150-200 | |
0-300A |
0-150V |
NHWY150-300 | |
0-500A |
0-150V |
NHWY150-500 |
0-200V 可调 |
0-2A |
0-200V |
NHWY200-2 |
0-3A |
0-200V |
NHWY200-3 | |
0-5A |
0-200V |
NHWY200-5 | |
0-10A |
0-200V |
NHWY200-10 | |
0-15A |
0-200V |
NHWY200-15 | |
0-20A |
0-200V |
NHWY200-20 | |
0-30A |
0-200V |
NHWY200-30 | |
0-50A |
0-200V |
NHWY200-50 | |
0-80A |
0-200V |
NHWY200-80 | |
0-100A |
0-200V |
NHWY200-100 | |
0-150A |
0-200V |
NHWY200-150 | |
0-200A |
0-200V |
NHWY200-200 | |
0-300A |
0-200V |
NHWY200-300 | |
0-500A |
0-200V |
NHWY200-500 |
0-300V 可调 |
0-2A |
0-300V |
NHWY300- |
0-1A |
0-300V |
NHWY300-1 | |
0-2A |
0-300V |
NHWY300-2 | |
0-3A |
0-300V |
NHWY300-3 | |
0-5A |
0-300V |
NHWY300-4 | |
0-10A |
0-300V |
NHWY300-10 | |
0-20A |
0-300V |
NHWY300-20 | |
0-30A |
0-300V |
NHWY300-30 | |
0-40A |
0-300V |
NHWY300-40 | |
0-50A |
0-300V |
NHWY300-50 | |
0-60A |
0-300V |
NHWY300-60 | |
0-80A |
0-300V |
NHWY300-80 | |
0-100A |
0-300V |
NHWY300-100 | |
0-200A |
0-300V |
NHWY300-200 |
0-400V 可调 |
0-1A |
0-400V |
NHWY400-1 |
0-2A |
0-400V |
NHWY400-2 | |
0-3A |
0-400V |
NHWY400-3 | |
0-4A |
0-400V |
NHWY400-4 | |
0-5A |
0-400V |
NHWY400-5 | |
0-8A |
0-400V |
NHWY400-8 | |
0-10A |
0-400V |
NHWY400-10 | |
0-15A |
0-400V |
NHWY400-15 | |
0-20A |
0-400V |
NHWY400-20 | |
0-25A |
0-400V |
NHWY400-25 | |
0-30A |
0-400V |
NHWY400-30 | |
0-40A |
0-400V |
NHWY400-40 | |
0-50A |
0-400V |
NHWY400-50 | |
0-100A |
0-400V |
NHWY400-100 |
0-500V 可调 |
0-1A |
0-500V |
NHWY500-1 |
0-2A |
0-500V |
NHWY500-2 | |
0-3A |
0-500V |
NHWY500-3 | |
0-4A |
0-500V |
NHWY500-5 | |
0-6A |
0-500V |
NHWY500-6 | |
0-8A |
0-500V |
NHWY500-8 | |
0-10A |
0-500V |
NHWY500-10 | |
0-12A |
0-500V |
NHWY500-12 | |
0-15A |
0-500V |
NHWY500-15 | |
0-20A |
0-500V |
NHWY500-20 | |
0-30A |
0-500V |
NHWY500-30 | |
0-40A |
0-500V |
NHWY500-40 | |
0-50A |
0-500V |
NHWY500-50 | |
0-100A |
0-500V |
NHWY500-100 |
0-600V 可调 |
0-1A |
0-600V |
NHWY600-1 |
0-2A |
0-600V |
NHWY600-2 | |
0-3A |
0-600V |
NHWY600-3 | |
0-5A |
0-600V |
NHWY600-5 | |
0-6A |
0-600V |
NHWY600-6 | |
0-8A |
0-600V |
NHWY600-8 | |
0-10A |
0-600V |
NHWY600-10 | |
0-15A |
0-600V |
NHWY600-15 | |
0-20A |
0-600V |
NHWY600-20 | |
0-25A |
0-600V |
NHWY600-25 | |
0-30A |
0-600V |
NHWY600-30 | |
0-40A |
0-600V |
NHWY600-40 | |
0-50A |
0-600V |
NHWY600-50 | |
0-100A |
0-600V |
NHWY600-100 |
0-800V 可调 |
0-1A |
0-800V |
NHWY800-1 |
0-2A |
0-800V |
NHWY800-2 | |
0-3A |
0-800V |
NHWY800-3 | |
0-5A |
0-800V |
NHWY800-5 | |
0-6A |
0-800V |
NHWY800-6 | |
0-8A |
0-800V |
NHWY800-8 | |
0-10A |
0-800V |
NHWY800-10 | |
0-15A |
0-800V |
NHWY800-15 | |
0-20A |
0-800V |
NHWY800-20 | |
0-25A |
0-800V |
NHWY800-25 | |
0-30A |
0-800V |
NHWY800-30 | |
0-40A |
0-800V |
NHWY800-40 | |
0-50A |
0-800V |
NHWY800-50 | |
0-100A |
0-800V |
NHWY800-100 |
0-1000V 可调 |
0-1A |
0-1000V |
NHWY1000-1 |
0-2A |
0-1000V |
NHWY1000-2 | |
0-3A |
0-1000V |
NHWY1000-3 | |
0-4A |
0-1000V |
NHWY1000-4 | |
0-5A |
0-1000V |
NHWY1000-5 | |
0-6A |
0-1000V |
NHWY1000-6 | |
0-10A |
0-1000V |
NHWY1000-10 | |
0-15A |
0-1000V |
NHWY1000-15 | |
0-20A |
0-1000V |
NHWY1000-20 | |
0-25A |
0-1000V |
NHWY1000-25 | |
0-30A |
0-1000V |
NHWY1000-30 | |
0-40A |
0-1000V |
NHWY1000-40 | |
0-50A |
0-1000V |
NHWY1000-50 | |
0-100A |
0-1000V |
NHWY1000-100 |
0-1200V 可调 |
0-1A |
0-1200V |
NHWY1200-1 |
0-2A |
0-1200V |
NHWY1200-2 | |
0-3A |
0-1200V |
NHWY1200-3 | |
0-4A |
0-1200V |
NHWY1200-4 | |
0-5A |
0-1200V |
NHWY1200-5 | |
0-6A |
0-1200V |
NHWY1200-6 | |
0-10A |
0-1200V |
NHWY1200-10 | |
0-15A |
0-1200V |
NHWY1200-15 | |
0-20A |
0-1200V |
NHWY1200-20 | |
0-25A |
0-1200V |
NHWY1200-25 | |
0-30A |
0-1200V |
NHWY1200-30 | |
0-40A |
0-1200V |
NHWY1200-40 | |
0-50A |
0-1200V |
NHWY1200-50 | |
0-100A |
0-1200V |
NHWY1200-100 |
0-1500V 可调 |
0-1A |
0-1500V |
NHWY1500-1 |
0-2A |
0-1500V |
NHWY1500-2 | |
0-3A |
0-1500V |
NHWY1500-3 | |
0-4A |
0-1500V |
NHWY1500-4 | |
0-5A |
0-1500V |
NHWY1500-5 | |
0-6A |
0-1500V |
NHWY1500-6 | |
0-10A |
0-1500V |
NHWY1500-10 | |
0-15A |
0-1500V |
NHWY1500-15 | |
0-20A |
0-1500V |
NHWY1500-20 | |
0-25A |
0-1500V |
NHWY1500-25 | |
0-30A |
0-1500V |
NHWY1500-30 | |
0-40A |
0-1500V |
NHWY1500-40 | |
0-50A |
0-1500V |
NHWY1500-50 | |
0-100A |
0-1500V |
NHWY1500-100 |
0-2000V 可调 |
0-1A |
0-2000V |
NHWY2000-1 |
0-2A |
0-2000V |
NHWY2000-2 | |
0-3A |
0-2000V |
NHWY2000-3 | |
0-4A |
0-2000V |
NHWY2000-4 | |
0-5A |
0-2000V |
NHWY2000-5 | |
0-6A |
0-2000V |
NHWY2000-6 | |
0-10A |
0-2000V |
NHWY2000-10 | |
0-15A |
0-2000V |
NHWY2000-15 | |
0-20A |
0-2000V |
NHWY2000-20 | |
0-25A |
0-2000V |
NHWY2000-25 | |
0-30A |
0-2000V |
NHWY2000-30 | |
0-40A |
0-2000V |
NHWY2000-40 | |
0-50A |
0-2000V |
NHWY2000-50 | |
0-100A |
0-2000V |
NHWY2000-100 |
