LY2507系列是采用CMOS技术开发的低压差,高精度输出、低消耗电流的正电压电压稳压器。由于内置了低通态电阻晶体管,所以输入输出电压差很小。能够获得较大的输出电流。特点:l, Maximum Output Current: 800 mA(VIN≥VOUT(T)+1.0V)
2, Dropout Voltage:,100mV@ IOUT =300mA,VOUT =5.0V
3, Operating Voltage Range: 2V~6.5V
4, Highly Accuracy: ±1%
5, Low Current Consumption:
During Operation: 82uA(TYP.)
During Shutdown:0.1uA(TYP.)
6,High Ripple Rejection: 65dB@1KHz (LY2507C50)
7, Line Regulation: 0.05%(TYP.)
8,Small Packages: SOT-89-5,SOT23-5,SOT89-3 稳压IC,线性LDO系列 LY2507C18M
稳压IC,线性LDO系列 LY2507C33M
稳压IC,线性LDO系列 LY2507A50P
稳压IC,线性LDO系列 LY2507C50M
稳压IC,线性LDO系列 LY2507C50P
稳压IC,线性LDO系列 LY2507C50K
