技术指标参数表：

熔化量[200C(392F)环境下24小内]%.............................0
蒸发量[200C(392F)环境下24小时内]% ........................0.001
比量:[25C(77F)].........................大于2.3
热传导系数:W/m-k..............................大于0.671
热阻抗:c-in/W.........................小于0.06
抗弧强度:seconds............................120
疑固时间:[25C]...........................3min
接着强度:....................................25KG
绝缘系数:100Hz/kvac...................5.1  1000Hz/kvac............5.0
能耗系数:100Hz/kvac..............................0.005
                   1000Hz/kvac.....................0.001
