【商品名称】TJ-02C带防雷保护机柜专用插座(PDU)
【商品品牌】突破
【商品状态】 上架
【商品规格】TZ
【商品单位】每条
基本描述
输入部分
额定电压 250V
最大负载电流 16A
电源输入方式 电缆线 3× 1.5mm2
电源输入连接器 10A/16A中国标准插头;13A 英标插头(BS1363式,带熔断器)、16A欧式(俗称德标)插头(CEE7式)、10A/16A IEC320 插头、16A工业插头(IP44,符合IEC309-2,CEE17)等。
输出部分 输出单元制式 带插孔连锁保护的TOP专利多用插孔(适合IEC标准下的多种插头,包括中国、日本、澳大利亚/ 新西兰、英国、美国、印度/南非、瑞士、意大利等),10A/16A IEC320 插座(孔)、16A插座(孔)等。
输出单元 6位 (5位10A插孔, 1位16A插孔)
额定输出电流 10A/16A
最大输出总电流 16A
选配单元
热动能过载保护单元
4000W超大功率( 通过UL认证)
带过载保护 RCD(漏电防护)单元 保护动作电流:10mA
安装单元 “电涌M&G防护”单元 保护敏感电气设备、计算机和网络设备,避免电压尖峰电压造成的硬件和软件的损坏。电涌防护最大峰值电流:
]10000A(8/20μs);
响应时间:<10ns。
材料 外壳坚固的铝合金外壳,可保证电源插座的耐用性,强度和安全。
内部结构内部采用一体的黄铜电源带,锡磷青铜的插孔簧片,硬连线电气结构,无铆钉连接或无摩擦触点,可保 证接触良好并提高了长期满电气负荷下的可靠性。
产品规格 尺 寸 可定制
环境条件 工作温度0℃-55℃
相对湿度 10-90%
可根据用户需求定制如下内容:
a.增加防雷功能。
b.增加热动能过载保护功能。
c.按需制定线长和规格RVV3×1.0mm2 OR RVV3×1.5mm2。
d.更换插头
e.插孔数量可随意定制(19英寸机柜标准长度产品限9联,不含防雷、过载保护和开关、
插孔间距44mm)。
f.产品长度可随意定制(按照22 mm 单位长度增减)。
g.插孔间距可随意定制(按照22 mm 单位长度增减)。
h.插孔可按需更换为16A 国际插孔。
i.可配装10A 双断开关。
j.按需加工壳体表面颜色(常规为银白色、黑色、定制品有采购数量要求。插孔件、电源线和其他配件一般为白色或黑色)。
________________________________________
TJ-02C Power distribution units(PDU)
items General description
input Rated voltage 250V
Maximum current load 16A
Power input type Cable 3× 1.5mm2
Power connector 10A/16A CN plugs;13A BS plugs with fuse;16A UNI plugs;10A/16A IEC320 plugs;16A industrial plugs IP44 complied with IEC309-2&CEE17
output Output unit format TOP patented multi-purpose outlets with interlock protection;10A/16A IEC320 socket outlets; 16A socket outlets
Output units 6 outlets (5 10A outlets&1 16A outlet )
Rated output current 10A/16A
Maximum output current 16A
Selected fits Thermal overload protection The power reaches 4000W with overload protection achieved UL certification.
RCD(residual current devise) Current protection level: 10mA
Equipped device M&G surge protection It offers short distance protection for sensitive electronic equipments such as computers, network systems and prevents the damage of hardware and software caused by voltage spikes. The maximum discharge current is 10000A(8/20μs) and the response time is less than 1microsecond.
Materials Enclosure It is made of rigid aluminum alloy, ensuring the safety, durability and strength of the power sockets.
Interior structure Interior structure consists of one-piece Copper power belts, Phosphor Bronze jack strips and rigid connecting wires without rivet or friction, ensuring close contact and long-term reliability.
Product
specification Dimension It depends on request
Working condition Operating temperature 0℃-55℃
Relative humidity 10-90%
Any condition below is available on demand
a. equipped with lightning protection
b. equipped with thermal overload protection
c. length and specification of the wires (RVV3×1.0mm2 OR RVV3×1.5mm2)
d. interchangeable plug
e. number of the receptacles (19-inch cabinet with maximum outlets of 9 , without lightning, overload protection and switch, 44mm spacing)
f. length of the product (22mm as a step to increase or decrease)
g. distance between adjacent receptacles (22mm as a step to increase or decrease)
h. replaced with 16A international receptacle
i. provided with 10A double-break switch
j. the casing color (silver white, black, or customized ones as per quantity on demand. While receptacle, power cord and the other accessories are generally white or black)
