电镀电源,电镀整流器-概述:
我公司电源适用于镀镍、镀锌、镀铬、镀锡等各种电镀场所。节电显著(较普通电源可节电10%-30%),电镀效果好。
在电镀电源电流10A~20000A, 电镀电压3V~600V内,可根据客户要求快速定制各类特殊规格用于不同功能用途的大功率电镀电源产品。
电镀电源,电镀整流器-特点:
1、降低孔隙率,晶核的形成速度大于成长速度,促使晶核细化。
2、改善结合力,使钝化膜击穿,有利于基体与镀层之间牢固结合。
3、改善覆盖能力和分散能力,高的阴极负电位使普通电镀中钝化的部位也能沉积,减缓形态复杂零件的突出部位由于沉积离子过度消耗而带来的“烧焦”、“树枝状”沉积的缺陷,对于获得一个给定特性镀层(如颜色、无孔隙等)的厚度可减少到原来1/3-1/2,可节省原材料。
4、降低镀层的内应力,改善晶格缺陷、杂质、空洞、瘤子等,容易得到无裂纹的镀层,减少添加剂。
5、有利于获得成份稳定的合金镀层。
6、改善阳极的溶解,不需阳极活化剂。
7、改进镀层的机械物理性能,如提高密度降低表面电阻和体电阻,提高韧性、耐磨性、抗蚀性而且可以控制镀层硬度。
8、提高产品成品率、产品质量。
Power supply made in this Company is applied for nickel-galvanized, zinc-galvanized, chrome-galvanized, tin-galvanized and relevant galvanized sites. It features greater power save (10%-30% more than that of normal power supply) and better galvanized effectiveness. Product features as follows:
1. Reduce porosity, formation for crystal core is more than growth rate, and promote Fineness for crystal core.
2. Improve combination force to make passive film punctured, and benefit for tight combination between basic body and galvanized coat.
3. Improve coverage capacity and dispersion one, higher cathode minus electric potential makes passive part in normal galvanization also sediment, mitigate highlighting part with complex-shaped part defective for burnt branched sedimentation arising from excessive consumption for sediment ion, As for thickness of special galvanized coat (i.e. color or free clearance), it may reduce 1/3 to 1/2 original one, so this saves raw material.
4. Reduce inherent stress for galvanized coat, improve defect, foreign matter, hollow hole and tumor at crystal lattice, easily obtain free galvanized coat, and reduce additive.
5. Benefit for obtaining alloy galvanized coat with stable ingredient.
6. Improve dissolution for anode without any activated agent at anode.
7. Improve mechanical and physical performance for galvanized coat, for example, improving compactness, reducing surface resistance and body one, improving flexibility, Abrasion resistance, anticorrosion and may control galvanized hardness.
8. Improve ratio of finished product and product quality.
电镀电源,电镀整流器-技术参数:
输入电压 |
AC380V/AC220V |
输出特性 |
恒流/恒压可转换 ( 0~额定值 ) |
输出波形 |
高频方波、直流及叠加波形 |
调节精度 |
≤1% |
效 率 |
≥89% |
功率因数 |
≤90% |
保护方式 |
过压、欠压、过热、过流 |
冷却方式 |
风冷或水冷 |
可选配置 |
PLC接口 |
环境温度 |
-20℃-45℃ |
环境湿度 |
≤80% |
绝缘等级 |
B级 |
防护等级 |
IP20 |
电镀电源,电镀整流器-相关产品规格型号:Specs and model for relative product
型号 Model |
规格/MM Specs(MM) |
冷却方式 Cooling method |
输出电流/DC.A Output current (DC.A) |
输出电压/DC.V Output voltage (DC.V) |
重量/kg Weight(kg) |
GGDF-50/12 |
350х300х250 |
风冷Air-cooling |
50 |
12 |
15 |
GGDF-100/12 |
400х365х250 |
风冷Air-cooling |
100 |
12 |
20 |
GGDF-500/12 |
380х290х590 |
风冷Air-cooling |
500 |
12 |
30 |
GGDS-500/12 |
340х340х220 |
水冷Water-cooling |
500 |
12 |
18 |
GGDF-1000/12 |
340х440х650 |
风冷Air-cooling |
1000 |
12 |
45 |
GGDS-1000/12 |
340х480х380 |
水冷Water-cooling |
1000 |
12 |
35 |
GGDF-2000/12 |
340х440х650 |
风冷Air-cooling |
2000 |
12 |
48 |
GGDS-2000/12 |
340х480х380 |
水冷Water-cooling |
2000 |
12 |
35 |
GGDF-3000/12 |
600х600х790 |
风冷Air-cooling |
3000 |
12 |
80 |
GGDS-3000/12 |
550х400х720 |
水冷Water-cooling |
3000 |
12 |
60 |
GGDF-4000/12 |
650х600х1075 |
风冷Air-cooling |
4000 |
12 |
90 |
GGDS-4000/12 |
640х400х850 |
水冷Water-cooling |
4000 |
12 |
70 |
GGDF-5000/12 |
700х650х1365 |
风冷Air-cooling |
5000 |
12 |
120 |
GGDS-5000/12 |
720х420х910 |
水冷Water-cooling |
5000 |
12 |
90 |
GGDF-6000/12 |
700х650х1365 |
风冷Air-cooling |
6000 |
12 |
150 |
GGDS-6000/12 |
720х420х910 |
水冷Water-cooling |
6000 |
12 |
110 |
GGDS-8000/12 |
820х600х1175 |
水冷Water-cooling |
8000 |
12 |
150 |
GGDS-10000/12 |
820х600х1175 |
水冷Water-cooling |
10000 |
12 |
180 |
GGDS-15000/12 |
1050х800х1800 |
水冷Water-cooling |
15000 |
12 |
350 |
GGDS-20000/12 |
1200х800х2160 |
水冷Water-cooling |
20000 |
12 |
500 |
GGDS-10000/15 |
820х600х1175 |
水冷Water-cooling |
10000 |
15 |
205 |
GGDS-15000/15 |
1050х800х1800 |
水冷Water-cooling |
15000 |
15 |
405 |
GGDS-20000/15 |
1200х800х2160 |
水冷Water-cooling |
20000 |
15 |
600 |
★ 我司可据客户要求快速定制各类特殊规格用于不同功能用途的大功率电源产品。
(电流10A~20000A,电压3V~600V),生产周期一周左右。
产品一年免费保修,终身维护,可免费为客户培训维修人员
