输入/输出规格参数[Input/Output Specifications]:

         输入电压[Input Voltage]:                          AC 100-240V,50/60Hz

         输出功率[Output Power]:                           24W

         输出电压[Output Voltage]:                         3V-36V

         输出电流[Output current]                          0.1A-2.5A

         过压保护[Over Voltage Protection]:                120%min

         过流保护[Over Current Protection]:                120%min

         短路保护[Short Protection]:                       Auto Recove

输出电压变动[Load Regulation]:                     ±5%

一般参数规格[General Specifications]

         工作环境温度[Operating Temperature]:              0~40℃

         储存温度[Storage Temperature]:                    -20~85℃

         工作温度[Operating Relative Humidity]:            5~95%RH

         耐压[Withstanding Voltage]:                       AC 2000V(Min),5mA(Max)

         绝缘抗体[Insulation Resistance]:                  DC 500V  100MΩ(Min)

用途[Application]:

        电脑.安防 监控.仪表 仪器.数码相框.

音响 多媒体产品.灯饰.电话机.按摩器.

电池充电器.交换机.玩具 .LED产品.通讯产品等等
