输入输出规格(Input/Output Specifications)
输入电压(input voltage):AC100~240V,50/60HZ
输出功率(output power):24W
输出电压(output voltage):DC3V~36V
过压保护(Over Voltage Protection):120%min
短路保护(Short Protection):Auto Recovery
输出电压变动率(Load Regulation):5%
工作环境温度(Operation Temperature):0~40℃
开关电源适配器产品常用参数选型列表(输出DC电压)
3V | 5V | 6V | 9V | 12V | 15V | 24V | 30V | 36V | >>> |
2A | 2A | 2A | 2A | 1A | 1A | 1A | 1A | 0.5A | >>> |
2.5A | 2.5A | 2.5A | 2.5A | 2A | 2A | 1.5A | 0.5A | >>> | |
3A | 3A | 3A | 2.5A |
外壳尺寸(Shell Size):86*44*53mm
