Voltage Accuracy

±1.0% max

Line Regulation

Single

±0.2% max

Dual

±0.5% max

Load Regulation

3.3 & 5V

±0.5% max

12 & 15V

±0.2% max

Dual

±1.0% max

Ripple & Noise (20MHz)

3.3 & 5V

75mVP-P typ

Others

100mVP-P typ

Switching Frequency

330kHz typ

Efficiency

Up to 90%

Short Circuit

Continuous

Isolation Voltage

1500VDC

Isolation Resistance

1000M? min

Isolation Capacitance

1500pF max

Operating Temperature

-40°C to +55°C

Remote On/Off

Enable High

Output Trim

±10% min

MTBF

1,000,000 hours min

Case Material

Metal, non-conductive baseplate

Model Selection Guide

Model               Number

Input    Voltage

VDC

Output    Voltage

VDC

Output

Current

mA max

MJWI20-24S033

3.3

4500

MJWI20-24S05

5

4000

MJWI20-24S12

24

12

1670

MJWI20-24S15

( 9 – 36 )

15

1340

MJWI20-24D12

±12

±835

MJWI20-24D15

±15

±670

MJWI20-48S033

3.3

4500

MJWI20-48S05

5

4000

MJWI20-48S12

48

12

1670

MJWI20-48S15

( 18 – 75 )

15

1340

MJWI20-48D12

±12

±835

MJWI20-48D15

±15

±670
